Jabsco Toilet Macerator Pump – 24 Volt 46LPM 18590-2094

Description Jabsco Toilet Macerator Pump – 24 Volt 46LPM 18590-2094 The Jabsco toilet macerator pump is also ideal for evacuation of live bait systems and fish boxes in larger installations. It macerates the leftovers into a slurry and evacuates it quickly and efficiently at up to 46 litres per minute. Inlet 1 1/2″ male thread and 38mm hose – Outlet 25mm Hose 8 amps Impeller: Jabsco Nitrile compound Macerator: Stainless Steel Cutter reduces particle size to 1/8″ (3mm) maximum. New 4blade design. Seal: Lip Type WASTE EVACUATION The Jabsco 18590 series DC macerator pump unit is the ideal solution for emptying marine holding tanks when not in a discharge restricted area. Self priming to 1.3 metres this pump will empty a typical 115 Litre holding tank in less than 3 minutes. Duty cycle of the pump is 15 minutes continuous which means a 680 liter can be emptied in a single operation. The Jabsco macerator is the ideal answer to simple holding tank pump-outs. 46 litres per minute output – 38 litres per minute at 3 metre head Triple sealed motor to prevent corrosion Run-dry protection sensor device New 4 blade stainless steel chopper reduces clogging even further Self priming up to 1.3 metres vertical lift Macerates and discharges air, water and waste mixtures Connections : Inlet 1 1/2″ male thread and 38mm hose Outlet 25mm 1″ hose It is recommended that holding tanks be flushed with several gallons of water after each pump out. This will reduce the possibility of a continued build up of sediment in the tank which could cause a potential blockage. FISH BOX AND LIVEWELL TANK EVACUATION The Jabsco Macerator Pump is the ideal pump for the emptying of fish box and livewell receptacles. Very often the livewell tank will be above the waterline of the boat, when this is the case gravity can be used to empty the livewell tank. If not installed in this format then it is beneficial to use the Jabsco macerator pump for evacuation due to its self-priming capabilities and also it’s grinding properties. Fish boxes are typically mounted into the floor of the vessel and are very often below the waterline or only partially above the waterline. Again the Jabsco Macerator pump has the characteristics that lend themselves to this application. The bait residue particles of ice, fish scales and anything else that could potentially be found in the Fish-Box will be easily passed buy the Jabsco Macerator Pump, and the self priming capabilities are perfect for fish box installations common to many of today’s sports fishing boats. New version with patented run dry protection device, heavy duty corrosion resistant triple sealed motor and a more powerful 4 blade stainless steel chopper to further reduce the possibility of clogging. The Jabsco macerator is the ideal answer to simple holding tank pump-outs. 46 litres per minute output – 38 litres per minute at 3 metre head Triple sealed motor to prevent corrosion Run-dry protection sensor device New 4 blade stainless steel chopper reduces clogging even further Self priming up to 1.3 metres vertical lift Macerates and discharges air, water and waste mixtures Connections : Inlet 1 1/2″ male thread and 38mm hose Outlet 25mm 1″ hose   Length 294mm Height 82mm Width 119mm
